How Gas Chromatography (GC) Works and How to Interpret the Results

Gas Chromatography (GC) separates components of a mixture based on their volatility and interaction with the column material. The sample is vaporized, separated within a column, and detected as it exits. Interpreting results involves analyzing chromatograms, peak areas, and applying calibration methods to quantify components accurately.

Mechanism of Gas Chromatography

Sample Injection and Vaporization

The process begins with injecting a small volume of the sample into the GC instrument. The sample enters a vaporization chamber or liner, where it rapidly vaporizes due to high temperature. Once vaporized, the sample is carried by an inert gas, often helium or nitrogen, into the chromatographic column.

Separation within the Column

The column is housed inside an oven, and its temperature can be fixed or programmed to increase over time (temperature ramp). The column is coated with a stationary phase that interacts differently with each compound.

  • Compounds with higher affinity for the stationary phase move slower through the column.
  • Compounds weakly interacting with the stationary phase elute faster.
  • Some components may condense if the column or oven temperature is low, remaining temporarily stationary.
  • Increasing the oven temperature can vaporize these components again, allowing them to move through the column (temperature ramp effect).

The separation depends on molecular properties such as polarity, boiling point, and molecular weight. These factors affect how long each compound remains in the column before eluting.

Detection of Components

As compounds exit the column, they pass through a detector. Different detectors exist: flame ionization detectors (FID), thermal conductivity detectors (TCD), or mass spectrometers (GC-MS). Each detector produces a signal proportional to the amount of compound present.

The detector records signals over time, generating a chromatogram. Each peak corresponds to a different component eluting at a specific retention time.

Interpreting GC Results

Chromatograms and Peak Areas

A chromatogram plots detector response against time. Each peak on this graph represents a compound.

  • The peak’s position (retention time) helps identify the compound.
  • The peak’s area reflects the quantity present.

Quantitative analysis often involves comparing each peak’s area to the total integrated peak area. This yields the area percent (area%), expressing the relative amount of each compound in the mixture.

Calibration and Quantification

Simple area% comparison provides relative abundance but not absolute quantity. Accurate quantification requires calibration.

  1. Calibration Curve: Prepare standards of known concentrations.
  2. Inject these standards and measure detector response (peak area).
  3. Plot concentration versus response to generate a calibration curve.
  4. Use this curve to convert peak area from unknown samples into actual concentration (e.g., mg/L, wt%).

This method corrects for differences in detector response for each analyte.

Response Factor (RF)

Response factor compares the known concentration to the measured detector response. For example:

Known Amount Injected Observed Area% Response Factor
1 unit 0.85 units 0.85 (underrepresented)

If compounds are underrepresented (RF < 1), measurements must be adjusted accordingly for accurate quantification.

Internal Standard Adjustment

Using an internal standard helps correct variations in sample preparation, injection, and detection:

  • Add a known amount of an internal standard to all samples and standards.
  • Detector response to the internal standard is compared to the expected value.
  • Adjust responses of analyzed compounds proportionally based on internal standard response differences.
  • This assumes all components experience the same variation in response.

Calibration Levels and Peak Identification

Multiple calibration levels (ranging from low to high concentrations) help improve identification and quantification of compounds.

By comparing sample retention times and peak shapes to those of standards across calibration levels, analysts assign compound names to peaks.

For example, a peak matching retention time of a 10 ppm standard suggests similar analyte identity and concentration estimation.

Purity Measurement

Purity is often assessed as the percentage area of the target compound’s peak compared to the total peak area in the chromatogram.

Alternatively, purity can be evaluated via a calibration curve using a reference standard.

A pure compound ideally shows one sharp peak. Additional peaks indicate impurities.

Purity calculation also considers limits of detection (LOD) and quantitation (LOQ) to exclude noise or insignificant signals.

Signal Identification and Integration

If reagents and samples are pure, only one or two peaks may appear. Software typically auto-integrates peak areas.

Assigning peaks to products or reagents requires:

  • Reference standards with known retention times.
  • Mass spectrometry coupling (GC-MS) to confirm compound identity from spectral data.

Accurate peak integration ensures quantitative comparison between components and aids in purity determination.

Summary of Key Concepts

  • GC separates compounds via vaporization, column affinity, and elution time differences.
  • Sample injection vaporizes components, carrier gas transports them through the column.
  • Detector records a chromatogram with peaks corresponding to separate compounds.
  • Peak retention time identifies compounds; peak area quantifies amounts.
  • Calibration curves convert area into absolute concentrations.
  • Response factors adjust for detector response variability.
  • Internal standards correct errors from sample processing and injection.
  • Purity calculated by comparing target peak area to total detected peaks.
  • Software integration and use of standards or MS spectra aid peak identification.
